Macnaught 50:1 Air Operated Grease Pump for 33LB to 44Lb Containers - PN# P3-01C
Macnaught’s 50:1 P3-01C air-operated grease pump system is engineered for 33 lb – 44 lb containers. It has the adjustable Collar meaning it fits 5 gallon as well as differing size pails 33lb to 44 lb.
- Mã SP:P3-01C
Giá: Liên hệ
Thông tin chi tiết
Macnaught 50:1 Air Operated Grease Pump for 33LB to 44Lb Containers - PN# P3-01C
Invest with Confidence: Macnaught's Warranty is the Best in the Business
Macnaught’s 50:1 P3-01C air-operated grease pump system is engineered for 33 lb – 44 lb containers. It has the adjustable Collar meaning it fits 5 gallon as well as differing size pails 33lb to 44 lb. Our Pneumatic Grease pumps have low air consumption motor & don’t need to be lubricated due to the use of modern polymer materials. Quiet air motor design – Meets all industry noise level standards. B2 Booster Gun – Boosts greasing pressure up to 10,000 psi. 50:1 ratio air motor delivers up to 16 oz/min of fast, efficient grease output. Users will save on power and avoid the oily mist and mess typically associated with air-operated equipment.
Macnaught P3-TR Specifications
| Model number | P3-01C – powerlube® |
|---|---|
| Pump ratio | 50:1 Ratio |
| Max pump output pressure | 7,500 psi / 517BAR |
| Max gun output pressure | 10,000 psi / 689BAR |
| Bare pump | P3003 |
| Suited to pails | 35lb – 44lb pails |
| Hose | 13ft x 1/4in ID delivery hose (4m x 6mm) |
| Control gun | B2 Booster Gun with ZSB swivel |
| Output at gun | 16 oz/min (460 g/min) |
| Airline Lubricator | Not required |
| Fully serviceable | ✔ |
| Warranty | 10 years |
| Parts guarantee | 10 years |
| Grease viscosity | Up to NLGI No.2 |
| Wetted components | Zinc, Hard Chrome-plated Carbon Steel, Brass, Nitrile and Polyurethane Rubber |
| Max air pressure | 150 psi |
| Min air pressure | 60 psi |
| Air inlet | 1/4″ NPT (F) |
| Pump Outlet | 1/4″ NPT (F) |
| Min compressor size | 3 cfm (0.08m³/ min) |
Macnaught P3-01C Features and Benefits
- Industry Leading 10-year Warranty
- Zinc components – For underground mining applications
- 50:1 ratio air motor delivers up to 16 oz/min of fast, efficient grease output
- Non-corroding air motor design – No airline lubricator required. Easy and low cost to repair
- Quiet air motor design – Meets all industry noise level standards
- 13’ ft high-pressure grease hose – Extra hose length for easier access to difficult applications
- B2 Booster Gun – Boosts greasing pressure up to 10,000 psi
- 360° ZSB Swivel – Improves greasing flexibility and offers easier one-handed operation
- KY Supergrip three-jaw high-pressure coupler – Positive no leak connection
- Rubber-edged follower plate – Prevents air pockets and contamination
- Fully sealed greasing system with built-in grease strainer – Clean grease delivery every time
- Fully repairable – Provides a longer service life
Macnaught P3-01C Data Sheet: PDF
Macnaught P3-01C Air Operated Grease Pump Instruction Manual: PDF
Very often purchased with PN# TR5 Trolley (See separate listing)
