ASCO Repair Kits C113825
The ASCO C113825 Repair Kit is a genuine replacement diaphragm assembly designed for ASCO Series 353 model 045/066 pulse jet valves. It restores reliable valve operation and ensures efficient pulse cleaning performance in industrial dust collection systems.
- Mã SP:C113825
Thông tin chi tiết
ASCO Repair Kits C113825
The ASCO C113825-2 is a replacement diaphragm kit specifically designed for ASCO Series 353 pulse jet valves. It is used during maintenance to replace worn diaphragms, helping restore valve performance and extend the service life of dust collection equipment.
Manufactured from high-quality elastomer materials, the diaphragm provides excellent sealing performance, fast response, and long operating life under demanding industrial conditions. It is commonly installed in reverse pulse jet cleaning systems for baghouse dust collectors.
Replacing the diaphragm at regular maintenance intervals helps minimize downtime, maintain cleaning efficiency, and reduce compressed air consumption.
Key Features
- Genuine ASCO diaphragm repair kit
- Designed for Series 353 pulse jet valves
- Compatible with G353A045 (1-1/2")
- Excellent sealing performance
- Fast diaphragm response
- Long service life
- Easy installation
- Ideal for industrial dust collection systems
Technical Specifications
Specification | Details |
|---|---|
Model/Part Number | C113825 |
Standards/Certifications | Compatible with ASCO valves certified to Ex, CE, IECEx, and ATEX standards |
Valve Size | For 1½" pipe connection pulse valves |
Diaphragm Material | NBR / BUNA |
Operating Temperature | -20°C to 85°C |
Operating Medium | Compressed Air |
Operating Pressure (PS) | 0.35 - 8.5 bar |
Flow Capacity (KV) | 43 - 46 m³/h (for 1½" valve) |
